TRANSFORMER

변류기

모델명과 핵심 사양을 비교하고, 제품 상세에서 적용에 필요한 조건과 문의 경로를 확인하세요.

검색 결과 129개 · 6페이지 중 1페이지

Zero sequence (residual) current transformer (closed type) 공식 제품 이미지

변류기

Zero sequence (residual) current transformer (closed type) 시리즈 변류기

Zero sequence (residual) current transformer (closed type)

Model
Primary Current · Secondary Current · Rated continuous thermal current · Main loop current · Transformation ratio · Precision class · load · Inner diameter-length-width-height (mm)
ZMCTLY-30
1A · 0.5mA · 2A · 0~100A · 2000:1 · 0.5 · ＜500 · 30-76-67-25
ZMCTLY-46
1A · 0.5mA · 2A · 0~160A · 2000:1 · 0.5 · ＜500 · 46-98-86-28
상세 사양 보기
Zero sequence (residual) current transformer (closed type) 공식 제품 이미지

변류기

Zero sequence (residual) current transformer (closed type) 시리즈 변류기

Zero sequence (residual) current transformer (closed type)

Model
Primary Current · Secondary Current · Rated continuous thermal current · Main loop current · Transformation ratio · Precision class · load · Inner diameter-length-width-height (mm)
ZMCTLF01
1A · 0.5mA · 2A · 0~250A · 2000:1 · 0.5 · ＜500 · 35*150-198-99-45
ZMCTLF02
1A · 0.5mA · 2A · 0~630A · 2000:1 · 0.5 · ＜500 · 50*220-288-133.5-45
상세 사양 보기
Zero sequence (residual) current transformer (open-close type) 공식 제품 이미지

변류기

Zero sequence (residual) current transformer (open-close type) 시리즈 변류기

Zero sequence (residual) current transformer (open-close type)

Model
Primary Current · Secondary Current · Rated continuous thermal current · Main loop current · Transformation ratio · Precision class · load · Inner diameter-length-width-height (mm)
ZMCTLK-30
1A · 0.5mA · 2A · 0~100A · 2000:1 · 1.0 · ＜500 · 30-79-66-25
ZMCTLK-45
1A · 0.5mA · 2A · 0~160A · 2000:1 · 1.0 · ＜500 · 45-100-79-24
상세 사양 보기
